1：引言

        对于实时处理当中，我们实际工作当中的数据源一般都是使用kafka，所以我们一起来看看如何通过Flink来集成kafka

        Flink提供了一个特有的kafka connector去读写kafka topic的数据。flink消费kafka数据，并不是完全通过跟踪kafka消费组的offset来实现去保证exactly-once的语义，而是flink内部去跟踪offset和做checkpoint去实现exactly-once的语义，而且对于kafka的partition，Flink会启动对应的并行度去处理kafka当中的每个分区的数据。

        Flink整合kafka官网介绍

        https://ci.apache.org/projects/flink/flink-docs-release-1.9/dev/connectors/kafka.html

2：导入pom依赖

<!-- https://mvnrepository.com/artifact/org.apache.flink/flink-connector-kafka -->
<dependency>
    <groupId>org.apache.flink</groupId>
    <artifactId>flink-connector-kafka_2.11</artifactId>
    <version>1.9.2</version>
</dependency>
<dependency>
    <groupId>org.apache.flink</groupId>
    <artifactId>flink-statebackend-rocksdb_2.11</artifactId>
    <version>1.9.2</version>
</dependency>
<dependency>
    <groupId>org.apache.kafka</groupId>
    <artifactId>kafka-clients</artifactId>
    <version>1.1.0</version>
</dependency>
<dependency>
    <groupId>org.slf4j</groupId>
    <artifactId>slf4j-api</artifactId>
    <version>1.7.25</version>
</dependency>
<dependency>
    <groupId>org.slf4j</groupId>
    <artifactId>slf4j-log4j12</artifactId>
    <version>1.7.25</version>
</dependency>

3：将kafka作为flink的source来使用

        实际工作当中一般都是将kafka作为flink的source来使用

3.1：创建kafka的topic

        安装好kafka集群，并启动kafka集群，然后在node01执行以下命令创建kafka的topic为test

kafka-topics.sh --create --partitions 3 --topic test --replication-factor 1 --zookeeper node01:2181,node02:2181,node03:2181

3.2：代码实现

import java.util.Properties​
import org.apache.flink.contrib.streaming.state.RocksDBStateBackend
import org.apache.flink.streaming.api.CheckpointingMode
import org.apache.flink.streaming.api.environment.CheckpointConfig
import org.apache.flink.streaming.api.scala.{DataStream, StreamExecutionEnvironment}
import org.apache.flink.streaming.connectors.kafka.FlinkKafkaConsumer
import org.apache.flink.streaming.util.serialization.SimpleStringSchema
​
/**
  *  将kafka作为flink的source来使用
  */
object FlinkKafkaSource {
​
  def main(args: Array[String]): Unit = {
    val env = StreamExecutionEnvironment.getExecutionEnvironment
    //**隐式转换
    import org.apache.flink.api.scala._
    //checkpoint**配置
    env.enableCheckpointing(100)
    env.getCheckpointConfig.setCheckpointingMode(CheckpointingMode.EXACTLY_ONCE)
    env.getCheckpointConfig.setMinPauseBetweenCheckpoints(500)
    env.getCheckpointConfig.setCheckpointTimeout(60000)
    env.getCheckpointConfig.setMaxConcurrentCheckpoints(1)
    env.getCheckpointConfig.enableExternalizedCheckpoints(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN_ON_CANCELLATION)
    //设置statebackend
    env.setStateBackend(new RocksDBStateBackend("hdfs://node01:8020/flink_kafka_sink/checkpoints",true));
​
    val topic = "test"
    val prop = new Properties()
    prop.setProperty("bootstrap.servers","node01:9092,node02:9092,node03:9092")
    prop.setProperty("group.id","con1")
    prop.setProperty("key.deserializer", "org.apache.kafka.common.serialization.StringDeserializer");
    prop.setProperty("value.deserializer", "org.apache.kafka.common.serialization.StringDeserializer");
    val kafkaConsumer = new FlinkKafkaConsumer[String]("test",new SimpleStringSchema,prop)
    kafkaConsumer.setCommitOffsetsOnCheckpoints(true)
    val kafkaSource: DataStream[String] = env.addSource(kafkaConsumer)
    kafkaSource.print()
    env.execute()​
  }
}

3.3：kafka生产数据

        node01执行以下命令，通过shell命令行来生产数据到kafka当中去

##创建topic
 kafka-topics.sh --create --topic test --partitions 3 --replication-factor 2 --zookeeper node01:2181,node02:2181,node03:2181
​
##发送数据
kafka-console-producer.sh --broker-list node01:9092,node02:9092,node03:9092 --topic  test

4：将kafka作为flink的sink来使用

        我们也可以将kafka作为flink的sink来使用，就是将flink处理完成之后的数据写入到kafka当中去。

4.1：socket发送数据

        node01执行以下命令，从socket当中发送数据

nc -lk 9999

4.2：代码实现

import java.util.Properties​
import org.apache.flink.contrib.streaming.state.RocksDBStateBackend
import org.apache.flink.streaming.api.CheckpointingMode
import org.apache.flink.streaming.api.environment.CheckpointConfig
import org.apache.flink.streaming.api.scala.StreamExecutionEnvironment
import org.apache.flink.streaming.connectors.kafka.FlinkKafkaProducer
import org.apache.flink.streaming.connectors.kafka.internals.KeyedSerializationSchemaWrapper
import org.apache.flink.streaming.util.serialization.SimpleStringSchema
​
/**
  * 将kafka作为flink的sink来使用
  */
object FlinkKafkaSink {
​
  def main(args: Array[String]): Unit = {
    val env = StreamExecutionEnvironment.getExecutionEnvironment
    //隐式转换
    import org.apache.flink.api.scala._

    //checkpoint配置
    env.enableCheckpointing(5000);
    env.getCheckpointConfig.setCheckpointingMode(CheckpointingMode.EXACTLY_ONCE);
    env.getCheckpointConfig.setMinPauseBetweenCheckpoints(500);
    env.getCheckpointConfig.setCheckpointTimeout(60000);
    env.getCheckpointConfig.setMaxConcurrentCheckpoints(1);
    env.getCheckpointConfig.enableExternalizedCheckpoints(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN_ON_CANCELLATION);
    //设置statebackend
    env.setStateBackend(new RocksDBStateBackend("hdfs://node01:8020/flink_kafka_sink/checkpoints",true));
    val socketStream = env.socketTextStream("node01",9999)
    val topic = "test"
    val prop = new Properties()
    prop.setProperty("bootstrap.servers","node01:9092,node02:9092,node03:9092")
    prop.setProperty("group.id","kafka_group1")
    //第一种解决方案，设置FlinkKafkaProducer里面的事务超时时间
    //设置事务超时时间
    prop.setProperty("transaction.timeout.ms",60000*15+"");
    //第二种解决方案，设置kafka的最大事务超时时间

    //FlinkKafkaProducer011<String> myProducer = new FlinkKafkaProducer<>(brokerList, topic, new SimpleStringSchema());

      //使用支持仅一次语义的形式
    /**
      * defaultTopic: String,
      * serializationSchema: KafkaSerializationSchema[IN],
      * producerConfig: Properties,
      * semantic: FlinkKafkaProducer.Semantic
      */
    val kafkaSink = new FlinkKafkaProducer[String](topic,new KeyedSerializationSchemaWrapper[String](new SimpleStringSchema()), prop,FlinkKafkaProducer.Semantic.EXACTLY_ONCE)
    socketStream.addSink(kafkaSink)​
    env.execute("StreamingFromCollectionScala")​
  }
}

4.3：启动kafka消费者

        node01执行以下命令启动kafka消费者，消费数据

kafka-console-consumer.sh --bootstrap-server node01:9092,node02:9092,node03:9092 --topic test
